MaxComm M200 4g router spec V1.03-EN
• 2G/3G/4G LTE data transmission.
• Power-on automatic network dialing.
• Built-in watchdog, system crashes self-recovery.
• Built-in link maintenance mechanism, data link dropped from self-recovery.
• 2*2 MIMO 4G LTE/WIFI antenna.
• Supports 2G/3G/4G LTE,WIFI funtion.
• Supports GPS funtion(Optional).
• One WAN/Four LAN(1 Gbps) ports.
• One console port, One USB port,RS232 or RS485 Interface.(Optional)
• SD data storage (Optional).
• With two SIM card slots, SIM card and network failure automatically switch.
• Remote management platform.
• Supports wifi 802.11AC, 1.2Gbit
• Supports 50 WiFi users sharing
• Firmware version: Openwrt 18.06
|
Item |
Product specification |
|
CPU |
MTK7621A |
|
MEMORY |
FLASH 16MByte, DDR2 64MByte |
|
Embedded system |
Openwrt 18.06 |
|
Network |
FDD LTE,TDD LTE,WCDMA,EVDO,GPRS,GSM,CDMA 1X |
|
WIFI |
WIFI 802.11 AC, 1Gbitbps |
|
Data rate |
4G LTE. CAT 4 , DL 150M , UL 50Mbps |
|
WCDMA HSPA+: DL 42Mbps, UL 5.76Mbps |
|
|
GPRS DL/UL 85.6Kbps |
|
|
WIFI Tx Power |
14 dBm（11g），17 dBm（11b），14dBm（11n） |
|
WIFI Rx Sensitivity |
<-70 dBm@54Mpbs |
|
2G/3G/4G Transmitting Power |
GSM/GPRS: Class 4 (2W): GSM850、EGSM900 Class 1 (1W): DCS1800、PCS1900 EDGE: Class E2 (0.5W): GSM850、EGSM900 Class E1 (0.4W): DCS1800、PCS1900 UMTS: Class 3 (0.25W): WCDMA Class 3 (0.25W): CDMA2000 Class 2 (0.25W): TD-SCDMA LTE: Class 3 (0.25W) |
|
GPS |
GPS/GLONASS,Protocol: NMEA |
|
WIFI Frequency |
2.4GHz/5.8GHz dual frequency bands |
|
Item |
Product specification ---4G version |
|
2G/3G/4G Frequency bands |
Version
C LTE TDD: B38/B39/B40/B41 WCDMA: B1/B8 TD-SCDMA: B34/B39 CDMA: BC0 GSM: 900/1800MHz
Version E LTE TDD: B38/B40/B41 WCDMA: B1/B8 GSM: B3/B8 Version AF LTE FDD: B2/B4/B5/B12/B13/B14/B66/B71 WCDMA: B2/B4/B5 Version J LTE FDD: B1/B3/B8/B18/B19/B26 LTE TDD: B41 WCDMA: B1/B6/B8/B19 Version AU LTE FDD: B1/B2①/B3/B4/B5/B7/B8/B28 LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: B2/B3/B5/B8
Version S |
|
Item |
Product specification |
|
Hardware interface |
1*WAN/4* LAN 1Gbps |
|
Storage memory |
Support SD data storage (Optional) |
|
RF |
High gain WIFI, 4G LTE, GPS antenna |
|
Security Encryption |
Support WEP、WPA、WPA2 encryption ways |
|
Protocol |
PPTP,L2TP,IPSEC VPN,TCP,UDP, DHCP,HTTP,DDNS,TR-069,GRE, HTTPS, SSH,Open VPN,SNMP |
|
Advertising push |
Support portal protocol, User login interface jump |
|
Data traffic management |
Support Traffic monitoring and bandwidth limitation |
|
LED Indicator |
“SYS”, “Net”, “WAN”, “LAN”,RSSI |
|
SIM/UIM |
Standard draw card interface, support 1.8V/3V SIM/UIM card, built-in ESD protection |
|
Key button |
Reset |
|
Standard Power |
DC input: DC 12V/1.5A |
|
Power Supply |
DC input: DC +6/2.5A~36V/0.5A |
|
Working current |
2.5A (Max Current) |
|
Temperature |
Operating Temperature -30~+70ºC |
|
Storage Temperature -40~+80ºC |
|
|
Environment humidty |
95% |
|
Case |
Black steel case |
|
Size |
155mm*105mm*25mm |
|
Weight |
225g |
