• MaxComm 4G LTE Cat.4 CPE WiFi Router WR-113

MaxComm 4G LTE Cat.4 CPE WiFi Router WR-113

Air Interface Technical Standard Compatible with  WCDMA, EVDO,TDD-LTE,FDD-LTE
802.11 b/g/n
Frequency Frequencies LTE/4G B2/B4/B5/B28
Frequencies 3G/UMTS 850MHz and 1900 MHz (B5 and B2)
E-UTRA (LTE) Cat. 4 (Up to 150/50 Mbps DL/UL)
WIFI 2.4GHz, WIFI 2*2 MIMO802.11 b/g/n
Performance Maximum Data Throughput LTE CAT 4
FDD-LTE 150Mbps/50Mbps
Theoretical peak rates
Hardware Receive Diversity Support Receive Diversity
MIMO Support DL 2x2 MIMO
BB Chipset Qualcomm MDM9207
RF Chipset Qualcomm WTR2965
WiFi Chipset RTL8192(802.11b/g/n)
Memory 4Gb+2Gb
power consumption <12W
Power Voltage DC12V/1.5A
support SIM/USIM/UIM,standard 6 PIN SIM card interface,
support 3V SIM card and 1.8V SIM card;internal
push-push SIM slot
LED  Power Indication LEDWAN Signal Strength WiFi/WPS Indication LED WAN/LAN Status LEDInternet Status LED,
Antenna  Internal Antenna /External antenna
USB USB-A 2.0 Optional
Buttons POWER,Reset,WPS
Ethernet 1WAN/LAN Port, 10BaseT/100BaseBase automatic adaptive port (4 LAN Port optional)
RJ11 RJ11x1
Reset Pinhole
ESD ESD Protection circuitContact±8KVAir±10KV
Software SW Update TR069 & Local Update Please check the TR069 sheet for details
WIFI Mode AP mode only
SMS & Phone Book Not Support by default, can be customized
Voice Not Support by default, can be customized Optional, Cost related
IPv4 Support IPv4
IPv6 Support IPv6
Firewall Mac/IP address filter, Port forwarding, WiFi Black/Whilte list
Data Statistics Support
VPN Pass Through PP2P/L2TP/IPSec
SIM Lock Support
WAN Fallback to ETH Manually
HTTP Support
Certification Depends on customization, cost related
Environment Operating Temperature Normal:-10°C to +65°C;
Storage Temperature -20° C  to +85° C
Humidity 5%~ 95%
