• MaxComm 5G WiFi Pocket Router MiFi MF-201

MaxComm 5G WiFi Pocket Router MiFi MF-201

Model : MF-201

MiFiMF-201 5G MiFi is a portable, broadband wireless device that functions as a modem, router and access point all in one.An internal modem can access a single wireless signal, and an internal router can share the connection between multiple users and wireless devices.Support for multiple users at the same time, including digital cameras, laptops, games and multimedia players, all Wi-Fi-enabled devices can access the Internet.5G MiFi can be used to set up specific networks and share network connections anywhere via cellular connections.Plug in a 5G SIM card and convert the 5G signal to high-speed Wi-Fi so that non-5G devices can also enjoy 5G high-speed.
Basic Information
Form Factor
Mobile WiFi
Dimension
about 130*70*19.5mm
Weight
about 200g
Color
Black& blue
Air Interface
Technical Standard
5G/4G/3G
802.11 a/b/g/n/ac/ax
Frequency
EA:
5G NR Sub-6G: N1/N3/N5/N7/N8/N20/N28/N38/N40/N41/N77/N78/N79;
LTE-FDD:B1/B3/B5/B7/B8/B20/B28/B32
LTE-TDD:B38/39/B40/B41/B46
WCDMA: B1/B3/B5/B8
SA:
5G NR Sub-6G:
N2/N5/N12/N25 /N41/N48/N66/N71/N77/N78
LTE-FDD:B2/B4/B5/B7/B12/B13/B14/B17/B25/B26/B29/B30/B66/B71
LTE-TDD: B41/B42/B43/B46/B48
WCDMA: B2/B4/B5
WiFi
2.4G&5G:WIFI 2*2 MIMO 802.11 a/b/g/n/ac/ax
Performance
Maximum Data Throughput
5G NR: 1.8Gbps/300Mbps
LTE CAT 18
FDD-LTE 1.2Gbps/150Mbps
Hardware
Receive Diversity
Support Receive Diversity
MIMO
Support DL 4x4 MIMO
BB Chipset
Qualcomm SDx55
WiFiChipset
QCA6391
Memory
4Gb+4Gb
T-card
NA
USB Charging
Type-C
USIM/SIM
4FF SIM card
Support SIM/USIM/UIM,standard 6 PIN SIM card interface, support 3V SIM card and 1.8V SIM card:internal
Battery
Li-ion Battery 5000mAh
Charging time
about 3H
Working time
about 8H
LCD
TFT LCD 2.4inch touch screen
USB
Type-C, Charge & internet
Antenna
5G+4G: 6 antennas
WiFi: 2 antennas
Buttons
POWER, Reset
IP RATING
NA
ESD
ESD Protection circuit, Contact ±8KV,Air ±10KV
Environment
Operating Temperature
Normal:-10℃~+45℃
Storage Temperature
-20℃~ +70℃
Humidity
5% ~ 95%
Specification
